PA Multilayer Sheet Extrusion Line High Barrier 800-1600mm Width

Product Categories
China Gwell Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

PA Multilayer Sheet Extrusion Line High Barrier 800-1600mm Width

  • 1
  • 2
  • 3

Brand Name : GWELL

Model Number : GWS65/105/65/75/65/75

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 200 sets per year

Delivery Time : 90 days

Packaging Details : STRETCHING FILM, PLASTIC FILM PACKAGE, WOODEN CASES PACKAGE FOR KEY PARTS

Product name : PA Multilayer Sheet Extrusion Line PA High Barrier Sheet Production Machine

Machine type : Plastic sheet extrusion line

Brand : Gwell

Suitable material : PP PS PE PA EVOH PVDC

Width : 800-1600mm

Thickness : 0.1-0.8

Screw design : Single screw

Country of origin : China

Warranty : One year

After-sales service : installation and machine debug

Contact Now

PA Multilayer Sheet Extrusion Line PA High Barrier Sheet Production Machine

Plastic film has a certain shielding ability to small molecule gases, liquids and odor molecules. The permeability coefficient is usually used to indicate the size of the plastic barrier.

PA Multilayer Sheet Extrusion Line High Barrier 800-1600mm Width

Ⅰ. Introduction of PA multilayer sheet extrusion line

1. PA high barrier sheet has good barrier properties, which is better than PVDC sheet under high temperature condition, but not as good as PVDC sheet under room temperature. With our PA sheet production machine, customers can make three-layer sheet,five-layer sheet or seven-layer sheet. The raw materials used are PA, PS, PP, PVC, PE and HIPS. The product is usually used as food packaging.

PA Multilayer Sheet Extrusion Line High Barrier 800-1600mm Width

2. Gwell PA high barrier sheet extrusion line

Our PA high barrier sheet extrusion line adopts the co-extrusion technology of multiple extruders to produce multi-layer co-extruded composite PA high barrier sheet, such as ABA, ABCBA, ABCDCBA and other multi-layer structures, which are widely used in thermoforming and common food packaging,etc.

Our PA high-barrier sheet production line is equipped with precision multi-layer distributors, which has the advantages of uniform layering, adjustable proportions of each layer, and precise digital control

PA Multilayer Sheet Extrusion Line High Barrier 800-1600mm Width

Ⅱ. Model table of PA multilayer sheet extrusion line

Machine

model

GWS65/105/65 single-screw extruder

GWS75/120/75 single-screw extruder

GWS65/65/65/65/65/75/75 single-screw extruder
Number of layers

Three layers/Five layers

Three layers/Five layers

Seven layers/Nine layers

Width

 800-1500mm 1200-1600mm

Thickness

 0.2-2mm

Output

 250kg/h-350kg/h 350kg/h-450kg/h 250kg/h-350kg/h

PA Multilayer Sheet Extrusion Line High Barrier 800-1600mm Width
